The ZX-NV14D is a helicopter pilot night vision goggle, which is designed for current pilot helmet platform interfaces.
It features a lightweight structural design for comfortable and flexible wear. Equipped with a domestically produced 3rd-generation image intensifier, it delivers clear imaging in extremely low-light environments.
Powered by an external battery compartment, it offers a continuous operational duration up to 60 hours.
This product enhances pilot's visual capabilities in dark environments, improves situational awareness, and boosts flight safety as well as special mission performance.
It can also be utilized for nighttime visual training of helicopter pilots in darkroom settings.
| Specifications |
| Type: Binocular, dual-tube night vision goggles |
| Magnification: 1× |
| Image Intensifier Grade: 3rd generation |
| System Resolution: 64–72 lp/mm |
| Overall Resolution |
| 0.94 mrad (contrast 85%–90%, illumination 1×10⁻¹ lx) |
| 1.67 mrad (contrast 35%–40%, illumination 1×10⁻³ lx) |
| Observation Range |
| Under clear starlight conditions, recognition distance for ground building is no less than 1,000m. |
| Mean Time Between Failures (MTBF): 30,000 hours |
| Field of View: 40° |
| Continuous Operation Time: ≥60 hours |
| Sensitivity: ≥1,800 μA/lm |
| Environmental Resistance |
| Water and dust protection rating: IP67 or higher |
| Diopter Adjustment Range: -4D to +4D |
| Weight: 480g |
| Interpupillary Distance (IPD) Adjustment: Continuously adjustable |
| IPD Range: 51–75mm |
| Bright Light Protection: Equipped with automatic brightness protection |
| Mounting Compatibility: Adaptable to T/TK40 series helmets |
| Storage Temperature Range: -55°C to +70°C |
| Operating Temperature Range: -40°C to +60°C |
