It features a 3rd-generation autogain brightness-controlled image intensifier tube and a compact structure, making it suitable for various applications.
It can be worn on the head or handheld, and each eyepiece can independently flip up to 140° for rapid switching between combat modes under different lighting conditions, ensuring adaptability to any harsh operational environment.
The unique built-in body posture system automatically adjusts settings based on the user's current state. Once the night vision device is flipped up onto the helmet and not in use, it powers off automatically to reduce stray light emission from eyepieces, avoiding target exposure.
The ZX-NV31C automatically adjusts image brightness to adapt to different combat lighting conditions, enhancing nighttime operational capabilities.
| Specifications |
| Type: Binocular, dual-tube night vision device |
| Magnification: 1× |
| Image Intensifier Grade: 3rd generation |
| System Resolution: 68 lp/mm |
| Overall Resolution |
| 0.7 mrad (contrast 85%–90%, illumination 1×10⁻¹ lx) |
| 2.0 mrad (contrast 35%–40%, illumination 1×10⁻³ lx) |
| Observation Range |
| Clear starlight conditions: ≥500 m for identifying standing solider |
| ≥1000 m for identifying medium-sized vehicles |
| Mean Time Between Failures (MTBF): 30,000 hours |
| Field of View: 52° |
| Continuous Operation Time: 80 hours on a full charge |
| Sensitivity: 2150 μA/lm |
| Operating Environment: Total darkness (no light), moonlight, starlight, or dim lighting |
| Water & Dust Resistance: IP67 or higher |
| Diopter Adjustment Range: +5D to -5D |
| Weight: 580g |
| Interpupillary Distance (IPD) Adjustment: Continuous, customizable |
| IPD Adjustment Range: 50–80 mm |
| Bright Light Protection: Equipped with bright light protection |
| Mounting Method: Soft helmet mount with one FAST base-compatible helmet bracket |
| Storage Temperature: -55°C to +70°C |
| Operating Temperature: -40°C to +60°C |
| Thermal Fusion Option: Optional thermal fusion accessory for low-light and infrared fused imaging |
